Victor CNC LS7 291CC CI PM Seat 2.200/1.615 - Bare (77679)
000853477767954 interest-free payments or as low as $—/mo with Affirm. See if you qualify
Compatibility
- Platform
- LS/LT
- Vehicle-specific fitment
- Review application details below
- Need help?
- Confirm fitment with us before ordering — (714) 202-7886
We list the engine platform a part is built for. That is not year-and-trim application data, so it does not confirm a fit on your specific vehicle.
- Est. install labor: 13.0 hrs — $1,625 at $125/hr. Pick Install at HRC and a 20% labor deposit ($325) is due at checkout; the balance is due at completion.
- An estimate for a stock vehicle, not a quote — we confirm it in writing when you book, before any labor is authorized. Seized hardware, prior modifications, diagnosis and machine work are quoted separately; tuning is arranged through our tuning partner. Questions: (714) 202-7886.
- Warranty & track disclaimer — read before you race it.
- Shipping & returns — rates and RMA terms.
- Installed in-house in Huntington Beach, CA — labor & service policy.
- Affirm and PayPal available at checkout.
More ways to pay at checkout
Edelbrock Victor CNC® LS7 Cylinder Heads are one of the first aftermarket high-performance LS-style heads to feature a raised intake runner design that fits both stock and aftermarket LS7 intake manifolds and valvetrain setups. The raised runner and rolled valve angle increase overall flow capability, while an improved water jacket design improves thermal conductivity. These premium 110 BHN 355-T6 aluminum alloy cylinder heads (#77679) are designed with a 12° valve angle and 291 cc .220" raised intake runners to provide a better line of sight into the 69 cc chambers and allow for an improved short turn. The exhaust ports are also raised .100” to allow the use of stock and aftermarket manifolds, while the .400” raised rail works with aftermarket rockers. The 100% CNC-ported runners and combustion chambers optimize volume, atomization, and velocity. The 6-bolt design increases clamping capacity and greatly improves head gasket retention in high-horsepower and boosted applications in small and large cubic inch, hardcore street applications. It also makes it compatible with the advanced Edelbrock LS Race, GM LSX 6-bolt, and OEM 4-bolt blocks. Built to withstand race conditions, the .750”-thick deck surface and a reinforced solid rocker rail increase integrity, rigidity, and stability. The copper-infused powder metal seats received a 2.200” intake and 1.615” exhaust valve job. The heads are sold bare, but we recommend COMP shaft mount rocker system (#1523CPG), valves, and springs, or if you want to use single rockers like #1479-16, you will need our LS7 rocker stands (#54520-2).
- VICTOR CNC 291 220 LS7 6-BOLT FLANGE COPPER SEATS
- Requires COMP Shaft Mount Rockers. OEM LS7 Rocker Adaptor (Requires qty 2)
- Premium 110 BHN aluminum alloy, .220" raised intake port, .100" raised exhaust port, CI PM valve seats, 307cc or 291cc intake port volume, 2.250" or 2.200" x 1.615" valve job
| Part Type | Engine Cylinder Head |
|---|---|
| 10260 | Yes |
| 10253 | Rectangle |
| 10250 | 12° |
| 6627 | 291 cc |
| 10265 | No |
| 10671 | No |
| 10261 | No |
| 10255 | Manganese Bronze |
| 10025 | No |
| 8789 | No |
| 10024 | No |
| 9799 | No |
| Accessory Bolt Holes Drilled | Yes |
| Camshaft Style | Roller |
| Combustion Chamber Style | Heart |
| Cylinder Head Material | 356-T6 Aluminum |
| Cylinder Head Style | Bare |
| Intake Valve Job Diameter | 2.200" |
| Machined for O-Ring | No |
| Notes | 6-Bolt design compatible for both OEM & 6-Bolt blocks, 0.400" Raised Rocker Rail Requires COMP Shaft Mount Rockers OR part 54520; OEM LS7 Rocker Adaptor (Requires qty 2) |
| Oiling Style | Through Pushrod |
| Remanufactured | No |
| Spark Plug Style | Angle |
| Steam Holes Drilled | Yes |
| Valve Cover Mounting Style | Center Bolt |
| Valve Guides Included | Yes |
| Valve Seat Machine Style | 4-angle intake/4-angle exhaust |
| Valve Seats Machine | Yes |
| Valve Springs Included | No |
| Valve Stem Seals Included | No |
| Series | Victor CNC |
| RGL | WARNING: This product can expose you to Lead, which is known to the State of California to cause cancer or birth defects or other reproductive harm. For more information, visit www.P65warnings.ca.gov. |
| 10 | Aluminum |
| Fuel Injection Down Nozzles | No |
| Exhaust Port Location | Raised 0.100"" |
| Intake Runner Location | Raised 0.220"" |
| Deck Thickness | .750" |
| Construction Type | Bare |
| Grade Type | Race |
| Valve Seat Material | CI-PM (Copper Infiltrated Powdered Metal) |
| Quantity | Sold Individually |
| Family | Victor CNC |
| Deck Height | 9.240" |
| CNC Ported | Yes |
| Required Products | 54520 - ROCKER ARM STAND, FOR LS7 |
| Related Products | 146202B-LSXR 102mm Intake Manifold; LS7 60840001K2LUN-Crank & Rod Kit, LS (Non LS7 Type 5) 58X Reluctor 5497-LS7 Timing Cover (Fits RHS® or GM Blocks) 28875-Super Victor Small Block Chevy LS7 Intake Manifold EFI STD Flange 28905-Super Victor Small Block Chevy LS7 EFI Dominator Flange Intake Manifold 2887-Super Victor Small-Block Chevy LS7 Intake Manifold Carb 2890-Super Victor Small-Block Chevy LS7 Dominator Flange Carburetor Intake Manifold 146204-LSXHR 103mm Intake Manifold for LS7 Raised Rectangular Port |
| Cross sell / Upsell Part Numbers | 146202B-LSXR 102mm Intake Manifold; LS7 1479-16-GM LS Upgraded OEM Rocker Arms (LS7) 13704TL-KIT-GM LS7 & Gen V LT Rocker Arm Upgrade Kit & Installation Tool |
| 10271 | Yes |
| 10267 | Yes |
| 10266 | Yes |
| 6626 | 69 cc |
| 10254 | D-Port |
| 10247 | 93 cc |
| 10251 | 12° |
| 6634 | No |
| Weight | 22.5 lb |
| UPC | 00085347776795 |
| Country of Origin | China |
Verified fitment · 10 applications
- Chevrolet Camaro 7.0L (2014–2015)
- Chevrolet Corvette 7.0L (2006–2013)
| Part No. | 77679 |
|---|---|
| Brand | Edelbrock |
| Part Type | Engine Cylinder Head |
| Weight | 22.5 lb |
| UPC | 00085347776795 |
| Country of Origin | China |
Platform-level fitment (Ford + GM, Phase 1). We publish the engine platform a part is built for — not year-and-trim application data — so nothing here confirms a fit on a specific vehicle. Confirm fitment with us before ordering: (714) 202-7886.
