VALVE SPRINGS,1.290" PERFORMAN CE GM LS1 (26915-16)
0365840726764 interest-free payments or as low as $—/mo with Affirm. See if you qualify
Compatibility
- Platform
- LS/LT
- Vehicle-specific fitment
- Review application details below
- Need help?
- Confirm fitment with us before ordering — (714) 202-7886
We list the engine platform a part is built for. That is not year-and-trim application data, so it does not confirm a fit on your specific vehicle.
- Est. install labor: 6.0 hrs — $750 at $125/hr. Pick Install at HRC and a 20% labor deposit ($150) is due at checkout; the balance is due at completion.
- An estimate for a stock vehicle, not a quote — we confirm it in writing when you book, before any labor is authorized. Seized hardware, prior modifications, diagnosis and machine work are quoted separately; tuning is arranged through our tuning partner. Questions: (714) 202-7886.
- Warranty & track disclaimer — read before you race it.
- Shipping & returns — rates and RMA terms.
- Installed in-house in Huntington Beach, CA — labor & service policy.
- Affirm and PayPal available at checkout.
More ways to pay at checkout
With a .600" maximum lift, these Beehive Valve Springs were designed for hydraulic Roller cams. COMP Cams Beehive Valve Springs deliver increased valve train stability and a much lighter valve train. This is achieved with less spring pressure for better valve control and reduced weight of both the spring and retainer. The unique Beehive shape handles valve train stress more efficiently to eliminate damaging harmonics and increases high RPM horsepower and durability. The oval/multi-arc wire shape places the maximum area of the wire at the point of highest stress to handle valve train stress more efficiently and allow better heat dissipation for longer life. Because of the unique Beehive design, the valve train can handle more RPM and more aggressive Camshaft profiles.
| Part # | OD | ID | Seat Load | Open Load | Coil Bind | Rate (Lbs./In.) | Titanium Retainer | Steel Retainer | Cup Seat | Shims | |
| 26915 | Top Bottom | 1.0551.290 | .650.885 | 105 @ 1.800 | 293 @ 1.200 | 1.100 | 313 | 762, 772, 788 | 761, 774, 783, 787, 795, 1787 | 4705 | 4753 |
| Part Type | Engine Valve Spring Kit |
|---|---|
| Coil Bind Height | 1.1" |
| Compatible .570" Guide Diameter Spring Seats | 4705-16 |
| Compatible Retainer | 788-16 |
| Compatible Shims | 4753 |
| Damper | No |
| Number of Springs | 1 |
| Outer Bottom Spring Inside Diameter | 0.885" |
| Outer Bottom Spring Outside Diameter | 1.29" |
| Outer Top Spring Inside Diameter | 0.65" |
| Outer Top Spring Outside Diameter | 1.055" |
| Seat Height | 1.8" |
| Seat Pressure | 105 |
| Spring Rate | 313 |
| Title | Performance Street 1.290" OD Beehive Spring; 1.800" Installed Height; 16 Springs |
| Valve Spring Series | Performance Street |
| Amazon ASIN | B000CIUBHW |
| C.A.R.B. Exempt for Racing and Off-Road Only Vehicles? | Yes, but must be a race/competition only vehicle. |
| C.A.R.B. Exempt for Federally Certified Vehicles Manufactured Before 1967? | Yes, but must meet tailpipe emission standards for year of vehicle. |
| C.A.R.B. Exempt for California Certified Vehicles Manufactured Before 1965? | Yes, but must meet tailpipe emission standards for year of vehicle. |
| C.A.R.B. Exempt for Foreign Vehicles Manufactured Before 1967? | Yes, but must meet tailpipe emission standards for year of vehicle. |
| C.A.R.B. Exempt for On-Road Vehicles? | Yes |
| C.A.R.B. Exemption Reason | No impact on pollution output of vehicle. |
| C.A.R.B. E.O. Number | N/A |
| California Proposition 65 | WARNING: Cancer and Reproductive Harm P65Warnings.ca.gov |
| Weight | 2.7 lb |
| UPC | 036584072676 |
| Country of Origin | USA |
Verified fitment · 19 applications
- Chevrolet Camaro (1998–2002)
- Chevrolet Corvette (1997–2004)
- Pontiac Firebird (1998–2002)
- Pontiac GTO (2004)
| Part No. | 26915-16 |
|---|---|
| Brand | COMP Cams |
| Part Type | Engine Valve Spring Kit |
| Weight | 2.7 lb |
| UPC | 036584072676 |
| Country of Origin | USA |
Platform-level fitment (Ford + GM, Phase 1). We publish the engine platform a part is built for — not year-and-trim application data — so nothing here confirms a fit on a specific vehicle. Confirm fitment with us before ordering: (714) 202-7886.
