Crate Engine #468900 Ford Coyote 302, Supercharged, 785 HP, 660 ft-lbs (468900)
000853479996444 interest-free payments or as low as $—/mo with Affirm. See if you qualify
Compatibility
- Platform
- Coyote 5.0
- Vehicle-specific fitment
- Review application details below
- Need help?
- Confirm fitment with us before ordering — (714) 202-7886
We list the engine platform a part is built for. That is not year-and-trim application data, so it does not confirm a fit on your specific vehicle.
- Est. install labor: 32.0 hrs — $4,000 at $125/hr. Pick Install at HRC and a 20% labor deposit ($800) is due at checkout; the balance is due at completion.
- An estimate for a stock vehicle, not a quote — we confirm it in writing when you book, before any labor is authorized. Seized hardware, prior modifications, diagnosis and machine work are quoted separately; tuning is arranged through our tuning partner. Questions: (714) 202-7886.
- Warranty & track disclaimer — read before you race it.
- Shipping & returns — rates and RMA terms.
- Installed in-house in Huntington Beach, CA — labor & service policy.
- Affirm and PayPal available at checkout.
More ways to pay at checkout
Edelbrock Supercharged 5.0L Ford Coyote crate engine part #468900 produced 785 hp and 660 ft-lbs. of torque (with 93 octane fuel) at the flywheel. The core of this engine is a brand new Ford aluminum block built for high performance applications. The lightweight aluminum block features a forged and balanced crankshaft, forged Manley H-Beam connecting rods and Mahle forged aluminum pistons. The 9.5:1 compression ratio allows for safe and reliable supercharged performance on 91 octane pump gas. Sitting on top is an Edelbrock supercharger with Eaton TVS R2650 rotors. Also included are the essential supercharger kit components such as the 8 rib belt drive, electric intercooler water pump, intercooler plumbing and intercooler recovery tank, as well as fuel rails, 60 lb./hr. fuel injectors, coils, mass air flow sensor (MAFS) housing and re-usable air filter. Includes all front end drive accessories: water pump, alternator, idlers, tensioners, belts and hardware. Pair with universal heat exchangers for a complete installation. Engine Specifications: Finish: Black powder coated
| Part Type | Engine Complete Assembly |
|---|---|
| Cylinder Head Type | Ford Racing |
| Horsepower | 785 |
| Spark Plugs Included | Yes |
| Calibration | No |
| Compression Ratio | 9.5:1 |
| Crankshaft Material | Forged Steel |
| Distributor Included | No |
| ECU Included | No |
| Oil Pan Included | Yes |
| Rocker Arm Ratio | 2:1 |
| Plug Wire and Boot Included | Yes |
| Main Bearing Cap Bolt Quantity | 4-Bolt |
| Cylinder Head Material | Aluminum |
| Torque | 660 |
| Manifold Material | N/A |
| Universal Or Specific Fit | Specific Fit |
| Pulley Belt Width | 8-Rib |
| Displacement | 302 cid |
| Engine Block Material | Cast Iron |
| Harmonic Balancer Included | Yes |
| Induction Type | Supercharged |
| RGL | WARNING: This product can expose you to Chromium, Lead, and Zinc which is known to the State of California to cause cancer or birth defects or other reproductive harm. For more information, visit www.P65warnings.ca.gov. |
| Timing Cover Included | Yes |
| Quantity | Sold Individually |
| Valve Cover Material | N/A |
| Hardware Included | Yes |
| Idler Pulley Included | Yes |
| Camshaft Type | Stock Ford |
| Air Cleaner Type | Not Included |
| Valve Cover Included | No |
| Carburetor Type | Not Included |
| Grade Type | Performance |
| Construction Type | Assembled |
| Rotor Type | Eaton TVS 2650, Black Powder Coated |
| Ignition Coil Included | Yes |
| Oil Filter Included | Yes |
| Piston Type | Forged Aluminum |
| Water Pump Included | Yes, Standard |
| Carburetor Choke Type | N/A |
| Intake Manifold Type | EFI |
| Valve Cover Type | N/A |
| Outside Pulley Diameter | 3.00" |
| Throttle Body Included | Yes |
| Type | Ford Coyote |
| Rocker Arm Type | Ford OEM |
| Rear Main Seal Type | 1-Piece |
| Wire Harness Included | Yes |
| Alternator Included | Yes |
| Flywheel Included | No |
| Weight | 726 lb |
| UPC | 00085347999644 |
| Country of Origin | USA |
Verified fitment · 14 applications
- Ford F-150 5.0L (2011–2017)
- Ford Mustang 5.0L (2011–2017)
| Part No. | 468900 |
|---|---|
| Brand | Edelbrock |
| Part Type | Engine Complete Assembly |
| Weight | 726 lb |
| UPC | 00085347999644 |
| Country of Origin | USA |
Platform-level fitment (Ford + GM, Phase 1). We publish the engine platform a part is built for — not year-and-trim application data — so nothing here confirms a fit on a specific vehicle. Confirm fitment with us before ordering: (714) 202-7886.
