McLeod Mag Force Clutch & Flywheel Kit – 3 Disc, Pin Drive, GM 1997-13 LS-X 6 Bolt Crank (651053-00-04)
008877533148334 interest-free payments or as low as $—/mo with Affirm. See if you qualify
Compatibility
- Platform
- LS/LT
- Vehicle-specific fitment
- Review application details below
- Need help?
- Confirm fitment with us before ordering — (714) 202-7886
We list the engine platform a part is built for. That is not year-and-trim application data, so it does not confirm a fit on your specific vehicle.
- Est. install labor: 10.0 hrs — $1,250 at $125/hr. Pick Install at HRC and a 20% labor deposit ($250) is due at checkout; the balance is due at completion.
- An estimate for a stock vehicle, not a quote — we confirm it in writing when you book, before any labor is authorized. Seized hardware, prior modifications, diagnosis and machine work are quoted separately; tuning is arranged through our tuning partner. Questions: (714) 202-7886.
- Warranty & track disclaimer — read before you race it.
- Shipping & returns — rates and RMA terms.
- Installed in-house in Huntington Beach, CA — labor & service policy.
- Affirm and PayPal available at checkout.
More ways to pay at checkout
Mag Force: 3 Disc: Pin Drive: GM 1997-13 LS-X 6 Bolt Crank: 1-1/8 x 10: 168T
Mag Force - These Clutches Are the Perfect Choice for Racers Looking for A Lightweight, High Torque Capacity Unit. They Are Designed to Be Used for Oval Track, Road Racing and Dry Lakes Applications. These Units Are Offered in Single Disc (500Ft Tq) Double Disc (900 Ft Tq) And Triple Disc (1500 Ft Tq) Configurations to Meet the Harshest Needs in The Industry. These Units Rely on A Pin Drive Actuation System Where the Floater Plate Slides On 6 Evenly Spaced Pins for Quick Release in A Racing Application. Our Mag Force Units Also Offer Bolt on External Balance Weights for Most Applications.
- Ceramic Discs
- Pin or Strap Drive
- Oval Track, Road Racing and Dry Lakes usage
- Single Disc (500Ft Tq)
- Double Disc (900 Ft Tq)
- Triple Disc (1500 Ft Tq
| Part Type | Transmission Clutch and Flywheel Kit |
|---|---|
| Disc Diameter (in.) | 8.000 |
| Input Shaft Diameter (in.) | 1.125 |
| Input Spline Quantity | 10 |
| Disc Material | Sintered Iron |
| Disc Style | Full face |
| Hub Style | Solid |
| Clutch Disc Quantity | 3 |
| Pressure Plate Style | Diaphragm |
| Clutch Usage | Performance |
| Hardware Included | Yes |
| Alignment Tool Included | Yes |
| Pilot Bushing Included | No |
| Throwout Bearing Included | No |
| Flywheel Included | Yes |
| Flywheel Material | Billet aluminum |
| Ring Gear Tooth Quantity | 168-tooth |
| Crankshaft to Flywheel Bolt Quantity | 6-bolt |
| Engine Balance | Internal |
| Quantity | Sold as a kit. |
Verified fitment — 267 applications
- Chevrolet
- Silverado 1500 2001–2006 (4.8L)
- Silverado 1500 2001–2006 (5.3L)
- Silverado 1500 2004 (6.0L)
- Silverado 1500 Classic 2007 (5.3L)
- Silverado 1500 Classic 2007 (4.8L)
- Silverado 1500 HD 2002 (6.0L)
- Silverado 2500 2001–2004 (6.0L)
- Silverado 2500 HD 2001–2006 (6.0L)
- Silverado 2500 HD Classic 2007 (6.0L)
- Silverado 3500 2001–2006 (6.0L)
- Silverado 3500 Classic 2007 (6.0L)
- GMC
- Sierra 1500 2001–2006 (5.3L)
- Sierra 1500 2001–2006 (4.8L)
- Sierra 1500 2004–2005 (6.0L)
- Sierra 1500 Classic 2007 (5.3L)
- Sierra 1500 Classic 2007 (4.8L)
- Sierra 2500 2001–2004 (6.0L)
- Sierra 2500 HD 2001–2006 (6.0L)
- Sierra 2500 HD Classic 2007 (6.0L)
- Sierra 3500 2001–2006 (6.0L)
- Sierra 3500 Classic 2007 (6.0L)
Ford & GM applications shown (ACES-verified). Confirm exact trim before purchase.
| Part No. | 651053-00-04 |
|---|---|
| Brand | McLeod Racing |
| Part Type | Transmission Clutch and Flywheel Kit |
| Weight | 27 lb |
| UPC | 00887753314833 |
Platform-level fitment (Ford + GM, Phase 1). We publish the engine platform a part is built for — not year-and-trim application data — so nothing here confirms a fit on a specific vehicle. Confirm fitment with us before ordering: (714) 202-7886.
